Client
The client is a leading machinery manufacturing company based in the Netherlands, specializing in producing high-precision equipment for various industries. Known for its commitment to quality and innovation, the company operates a large-scale manufacturing facility with complex material handling needs. To maintain its competitive edge, the client sought to upgrade its lifting equipment to ensure efficiency, safety, and compliance with European standards.
Timeline
The client first contacted us in May 2023. However because the customer reported that the factory was still under expansion, the purchase plan was temporarily shelved. During this time, our sales manager Dora actively contacted the customer and followed up on the expansion progress. Finally, in July 2024, the customer contacted us again and sent detailed inquiry parameters for the
bridge cranes.
Requirements
The client had specific requirements for their new
overhead crane systems:
- Capacity and Versatility: The bridge cranes needed to handle a range of loads, including three units with a lifting capacity of 25 tons each and one unit with a capacity of 12.5 tons.
- Precision and Safety: Given the nature of their operations, the 4 units of overhead cranes had to offer precise load control and incorporate advanced safety features.
- Compliance: The systems had to adhere to European standards and integrate seamlessly into their existing facility.
- Durability and Efficiency: The client required robust overhead bridge cranes capable of withstanding heavy usage while maintaining energy efficiency.
- Customization: The crane design had to be tailored to fit the unique layout and operational workflow of the plant.
Overhead Crane Design Solutions
After a thorough analysis of the client’s requirements and operational environment, DQCRANES proposed a solution featuring four QDX series
European standard double girder overhead cranes:
- Three 25 ton overhead cranes: Designed for handling heavy machinery components and raw materials.
- One 12.5 Ton Overhead Crane: Optimized for lighter loads and precision tasks.
This combination ensured the client had the flexibility to manage both heavy-duty and precision lifting operations efficiently.
Product: QDX model Euro-type double girder overhead crane
Country: Netherlands
- Capacity: 25 tons
- Span: 19.16m
- Lifting height: 9.74m
- Lifting mechanism: European-type hoist trolley
- Lifting speed: 0.5/3.3m/min
- Traveling speed: 45m/min
- Crane travel speed: 5~20m/min
- Control mode: Remote control
- Power source: 400V/50Hz/3PH
- Work duty: ISO A5/M5
- QTY: 3 units
Product: QDX model Euro-type double girder overhead crane
Country: Netherlands
- Capacity: 12.5 tons
- Span: 9.16m
- Lifting height: 10.225m
- Lifting mechanism: European-type hoist trolley
- Lifting speed: 0.8/5m/min
- Traveling speed: 45m/min
- Crane travel speed: 5~20m/min
- Control mode: Remote control
- Power source: 400V/50Hz/3PH
- Work duty: ISO A5/M5
- QTY: 1 unit
Design Features
- Double Girder Configuration: Ensures high load capacity and stability during operations.
- European Standards Compliance: The cranes were designed following FEM standards, ensuring safety, reliability, and performance.
- Variable Frequency Drives: Integrated into the hoisting and trolley mechanisms for smooth acceleration, deceleration, and precise positioning.
- Compact Design: Optimized to maximize headroom and workspace within the facility.
- Advanced Control Systems: Equipped with wireless remote controls and touch panel interfaces for ease of operation.
Other Benefits
- Energy Efficiency: Incorporates energy-saving technologies to reduce power consumption without compromising performance.
- Enhanced Safety: Features anti-sway technology, overload protection systems, emergency stop functions, and limit switches.
- Low Noise Operation: Designed to minimize noise levels, ensuring a more comfortable working environment.
- Smart Monitoring: Includes advanced diagnostics systems to monitor performance and predict maintenance needs.
- Custom Paint Coating: Applied with anti-corrosion treatment, ensuring long-term durability even in challenging environments.
Why the QDX Series?
At DQCRANES, the QDX series is a premium line of double girder overhead cranes designed to meet European standards for safety, efficiency, and reliability. These cranes are equipped with advanced technology and robust components, making them suitable for heavy-duty industrial applications. Key features of the QDX series include:
- European Standards Compliance: Ensures that the cranes meet stringent safety and performance criteria.
- Customization Options: Tailored designs that perfectly fit the client’s operational requirements.
- Proven Reliability: These FEM standards cranes have a strong track record of performance in various industrial applications.
- Cost-Effectiveness: Offers a balance between upfront investment and long-term operational savings.
- Comprehensive Support: Backed by DQCRANES’ end-to-end service, from design consultation to installation and after-sales support.
Timely Delivery
The
fem cranes manufacturing process was carried out at DQCRANES' state-of-the-art facility, leveraging advanced production techniques and stringent quality control measures. Each crane underwent rigorous testing to ensure compliance with European standards and optimal performance.
Once manufacturing was complete, the cranes were carefully packaged and transported to the Netherlands. Our logistics team coordinated every step of the export process to ensure timely delivery without any delays or damage.
