5 ton overhead crane and 5 ton overhead crane specifications

08 Dec, 2016

5 ton overhead crane for sale which amazes you with good price. Check the 5 ton overhead crane specifications and get your crane with good price. CE marked overhead cranes, electric hoist crane, magentic overhead crane, explosion proof overhead crane, European fem standard overhead crane, and other type of overhead crane with wide selection for sale at good crane price. Good crane quality, complete crane services, 20 days delivery!

5 ton overhead crane


  • Single girder overhead crane parts assembly

  • Double girder overhead crane parts assembly

  • FEM overhead crane parts assembly

5 ton overhead crane or bridge cranes are the most widely used lifting cranes for material handling. Dongqi Crane offers the 5 ton overhead cranes with the following 5 Ton Overhead crane specifications :

European Style Double Girder 5 ton overhead crane

European Style Double Girder 5 ton overhead crane

European double girder 5 ton overhead crane is designed according to European standards, which is welcomed by European countries.

  • European Style Double Girder 5 ton overhead crane Specification
  • Lifting Capacity 5~80t
  • Span Length ≥m
  • Working Class A5, A6
  • Ambient Temperature -20~40℃

LH Double Girder Electric Hoist Crane

Double girder electric hoist 5 ton overhead crane

The double girder hoist craneis very popular for high reliability and cost-effectiveness, which is applied in machinery processing workshop, warehouses, yard, plants, and other places, etc.

  • LH Double Girder Electric Hoist Crane Specification
  • Lifting Capacity 5~63t
  • Span Length 8m~32m
  • Working Class A3~A5
  • Ambient Temperature -20~40℃
  • 5 Ton Overhead Crane Specifications PDF Download: LH Double Girder Electric Hoist Crane

QD 5 ton overhead crane With Hook

5 ton overhead crane with hook - Dongqi double girder overhead crane

Hook 5 ton overhead crane is the most commonly used lifting equipment, which is widely used in the various factory or workshops, warehouse, stores, and other places, etc.

  • QD 5 ton overhead crane With Hook Specification
  • Lifting Capacity 5~550t
  • Span Length 10.5~35.5m
  • Working Class A4~A7
  • Ambient Temperature -20~40℃
  • 5 Ton Overhead Crane Specifications PDF Download: QD 5 ton overhead crane With Hook

QB Explosion Proof double girder 5 ton overhead crane

Explosion proof bridge craneis one type of various types of explosion-proof and hazardous environment material handling equipment which is widely used in factories and sites where is not higher than the II B or II C-class, and the sites with explosive air mixture formed with inflammable gas (or steam) and air whose factory ignition temperature groups of not less than the T4 group.

Explosion proof double girder 5 ton overhead crane

  • QB Explosion Proof Bridge Crane Specification
  • Lifting Capacity 5~75t
  • Span Length 10.5~31.5m
  • Working Class A4, A5
  • Ambient Temperature -20~40℃
  • Crane Specification PDF Download: QB Explosion Proof Bridge Crane

QC Electromagnetic 5 ton overhead crane

Electromagnetic 5 ton overhead crane

Electromagnetic 5 ton overhead crane is a kind of lifting equipment used to handle metal materials or objects such as, ingots, structural steel, iron, scrap iron, steel and others, etc.

  • QC Electromagnetic 5 ton overhead crane Specification
  • Lifting Capacity 5~32t
  • Span Length 10.5~31.5m
  • Working Class A5, A6
  • Ambient Temperature -20~40℃
  • 5 Ton Overhead Crane Specifications PDF Download: QC Electromagnetic 5 ton overhead crane

QE Double Trolley 5 ton overhead crane

5 ton overhead crane with two trolleys which can be used to handle heavy loads or objects. And the lifting capacity of the double trolley 5 ton overhead cranes are 5 ton to 400 ton.

Double trolley 5 ton overhead crane


Double trolley 5 ton overhead crane specification

  • Product Type: QE
  • Lifting Capacity: (2.5+2.5)~(200+200)t
  • Span Length: 10.5~35.5m
  • Working Class: A5, A6
  • Ambient Temperature -20~40℃
  • 5 Ton Overhead Crane Specifications PDF Download: QE Double Trolley 5 ton overhead crane

QY Insulation 5 ton overhead crane

Insulation 5 ton overhead crane

Insulation 5 ton overhead crane is a type of 5 ton overhead crane used in hazardous environment, such as, power plants, etc.

  • QY Insulation 5 ton overhead crane Specification
  • Lifting Capacity: 5~50t
  • Span Length 10.5~31.5m
  • Working Class A6
  • Ambient Temperature -25~50℃
  • 5 Ton Overhead Crane Specifications PDF Download: QY Insulation 5 ton overhead crane

QZ grab bucket 5 ton overhead crane

Grab crane for wastes handling - 5 ton overhead crane of Dongqi crane

Grab bucket 5 ton overhead crane is a heavy duty 5 ton overhead crane with the lifting capacity of 5 ton to 25 ton, which is widely used in power station, storage, smelting workshops of steel mill, waste recycling station, etc.

  • QZ Grab Bucket 5 ton overhead crane Specification
  • Lifting Capacity 5~25t
  • Span Length 10.5~34.5m
  • Working Class A6
  • Ambient Temperature -20~40℃
  • 5 Ton Overhead Crane Specifications PDF Download: QZ Grab Bucket 5 ton overhead crane

QDY Ladle 5 ton overhead crane

Ladle 5 ton overhead crane

Ladle 5 ton overhead crane is kind of 5 ton overhead crane designed especially for transporting, pouring and charging hot metal in the process of smelting liquid metal, etc.

  • QDY Ladle 5 ton overhead crane Specification
  • Lifting Capacity 5~74t
  • Span Length 10.5~31.5m
  • Working Class A7
  • Ambient Temperature -10~60℃
  • 5 Ton Overhead Crane Specifications PDF Download: QDY Ladle 5 ton overhead crane

LD Single Girder Electric Hoist Crane

Single girder hoist 5 ton overhead crane

Single girder electric hoist crane is a light lifting equipment which is used various environment, such as, factory, ware house, stockyard, etc.

  • LD Single Girder Electric Hoist Crane Specification
  • Lifting Capacity 1~32t
  • Span Length 7.5~28.5m
  • Working Class A3,A4
  • Ambient Temperature -20~40℃
  • 5 Ton Overhead Crane Specifications PDF Download: LD Single Girder Electric Hoist Crane

LB Explosion-proof Single Girder 5 ton overhead crane

Explosion proof single girder 5 ton overhead crane

Explosion proof single girder 5 ton overhead crane is a small 5 ton overhead crane with the lifting capacity of 1 ton to 20 tons which is wide used in inside factories with the detonating ability not high Ⅱ B or Ⅱ C, and flammable mixture environment with the Ignites temperature classes of T1 ~ T4 group;

  • LB Explosion-proof Single Girder 5 ton overhead crane Specification
  • Lifting Capacity 1~20t
  • Span Length 7.5~28.5m
  • Working Class A3
  • Ambient Temperature -20~40℃
  • 5 Ton Overhead Crane Specifications PDF Download: LB Explosion-proof Single Girder 5 ton overhead crane

LDP Low Headroom Single Girder 5 ton overhead crane

Low Headroom Single Girder 5 ton overhead crane

Low headroom single girder 5 ton overhead crane is a light duty material handling equipment, designed for low headroom workshop application.

  • LDP Low Headroom Single Girder 5 ton overhead crane Specification
  • Lifting Capacity 1~32t
  • Span Length 7.5~22.5m
  • Working Class A3, A4
  • Ambient Temperature -25~40℃

HD Electric Hoist 5 ton overhead crane

Electric Hoist 5 ton overhead crane

Electric hoist 5 ton overhead crane is a single girder 5 ton overhead crane developed by DQCANES with New Zealand advanced crane design concept and technology, confirming with international standards, i.e. DIN, FEM and ISO.

  • HD Electric Hoist 5 ton overhead crane Specification
  • Lifting Capacity 1~30t
  • Span Length ≥6m
  • Working Class A5
  • Ambient Temperature -25~40℃

NLX European Style Underslung Crane

European Style Underslung Crane

European single girder underslung crane is a light duty material handling equipment which can be installed on the roof of the workplace without bracket, saving space and lowering cost.

  • NLX European Style Underslung Crane Specification
  • Lifting Capacity 1~20t
  • Span Length ≥ 6m
  • Working Class A5
  • Ambient Temperature -25~40

LX Single Girder Suspension Crane

Single girder suspension 5 ton overhead crane

Single girder suspension 5 ton overhead crane is a kind of light duty material handling equipment, with the single girder running on the suspension track. The suspension 5 ton overhead crane is widely used for machine assembling, equipment installation, maintenance, etc.

  • LX Single Girder Suspension Crane Specification
  • Lifting Capacity 1~10t
  • Span Length 3~15m
  • Working Class A3
  • Ambient Temperature -20~40℃
  • 5 Ton Overhead Crane Specifications PDF Download: LX Single Girder Suspension Crane

Lifting capacity offering of Dongqi Hoist and crane for sale

  • 1 ton overhead crane for sale  1 ton overhead crane for sale
  • 2 ton overhead crane for sale  2 ton overhead crane for sale
  • 3 ton overhead crane for sale  3 ton overhead crane for sale
  • 5 ton overhead crane for sale  5 ton overhead crane for sale
  • 6 ton overhead crane for sale  6 ton overhead crane for sale
  • 7 ton overhead crane for sale  7 ton overhead crane for sale
  • 7.5 ton overhead crane for sale  7.5 ton overhead crane for sale
  • 8 ton overhead crane for sale  8 ton overhead crane for sale
  • 10 ton overhead crane for sale  10 ton overhead crane for sale
  • 12 ton overhead crane for sale  12 ton overhead crane for sale
  • 15 ton overhead crane for sale  15 ton overhead crane for sale
  • 20 ton overhead crane for sale  20 ton overhead crane for sale
  • 25 ton overhead crane for sale  25 ton overhead crane for sale
  • 30 ton overhead crane for sale  30 ton overhead crane for sale
  • 35  ton overhead crane for sale  35 ton overhead crane for sale
  • 40 ton overhead crane for sale  40 ton overhead crane for sale
  • 50 ton overhead crane for sale  50 ton overhead crane for sale
  • 60 ton overhead crane for sale  60 ton overhead crane for sale
  • 70 ton overhead crane for sale  70 ton overhead crane for sale
  • 75  ton overhead crane for sale  75 ton overhead crane for sale
  • 80 ton overhead crane for sale  80 ton overhead crane for sale
  • 90 ton overhead crane for sale  90 ton overhead crane for sale
  • 100 ton overhead crane for sale  100 ton overhead crane for sale
  • Custom overhead craneGet your custom overhead crane

5 ton overhead crane for sale with various type of cranes design are available. Custom 5 ton overhead crane is the cost-effective lifting solution in workstation, factory, warehouse, marble handling, steel factory, etc. Check types of 5 ton overhead cranes for sale, and get your 5 ton overhead crane lifting solution.

More information on overhead crane, gantry crane, jib crane and electric hoist, please feel free to contact us.
