Overhead travelling crane: Up to 320 ton overhead travelling crane for sale

21 Sep, 2017

Overhead travelling crane is a common lifting machine in the daily operation, and it is widely applied in different kinds of working occasions. Almost all Dongqi overhead travelling cranes takes I-beam structure in the main beam, besides, the crane can be customized into different types.

Main designes of overhead travelling cranes

As an overhead travelling crane manufacturer, Dongqi offers types of custom overhead travelling cranes designs for material handling market. In the following are the main products for for your reference. (Please click the picture for detailed information.)

Our travelling overhead travelling crane mainly include different types and usages of single girder overhead travelling crane＆double girder overhead travelling crane, such as explosion proof overhead travelling crane, bucket crane, free standing overhead travelling crane, underhung overhead travelling crane＆top running overhead travelling crane, electric hoist crane, foundry crane, etc.

Types of overhead travelling cranes designs

The main overhead travelling crane designs are as single girder overhead travelling crane, double girder overhead travelling crane, overhead travelling underhung cranes, European overhead travelling cranes, etc. Custom overhead travelling crane designs are also available from Dongqi Hoist and Crane.

Single girder overhead travelling crane designs

A single girder bridge crane is usually designed for the lifts under 20 tons, span less than 31.5m, or the requirement for crane services classification is under A7 and A8.

Single girder overhead travelling crane - overhead travelling crane types of Dongqi

The single girder overhead travelling crane consists of one girder beam supported on each side by an end truck. The electric trolley and hoist commonly run on the bottom flange of the bridge, often called single girder underhung overhead travelling crane. The single girder underhung crane is less expensive because of the following reasons:

Only one beam girder is needed to move the trolley and hoist.
Lower cost in freight.
Easy installation.
Hoist and trolley design is easier than those of double girder overhead travelling crane.

Single girder overhead travelling crane of Dongqi crane

The single girder overhead travelling crane is custom made, which means the overhead travelling crane size, lifting capacity and crane designs are perfectly suitable to your requirements and application environment. Dongqi Crane offers types of single girder overhead travelling crane for sale. The main specificaitons of single girder overhead travelling cranes are for your reference. Custuom single girder overhead travelling crane designs are available. Contact us to get your custom overhead travelling cranes.

	Electrical hoist single girder overhead travelling crane Electrical hoist single girder overhead travelling crane is widely used in the factory, ware house, stockyard, etc. Electrical hoist single girder overhead travelling crane specifications: Product type: LD single girder eot crane, Lifting capacity: 1~32t, Span length: 7.5~28.5m, Working class: A3,A4,
	Explosion proof single girder overhead travelling crane Explosion proof single girder overhead travelling crane is designed for hazardous environment, such as, gas, dusty environment to enhance safety. Explosion proof single girder overhead travelling crane specifications: Product type: LB single girder eot crane, Lifting capacity: 1~20t, Span length: 7.5~28.5m, Working class: A3,
	Low headroom single girder overhead travelling crane Low headroom single girder overhead travelling cranes are designed for low height plant and factory, where the lifting room is limited but lifting height is high. Low headroom single girder overhead travelling crane specifications: Product type: LDP single girder eot crane, Lifting capacity: 1~32t, Span length: 7.5~22.5m, Working class: A3, A4,
	FEM electrical hoist single girder overhead travelling crane FEM hoist single girder overhead travelling crane is designed with features of Sturdy quality,Good price, One year quality assurance, Full set of after sales service. European hoist single girder overhead travelling crane specification: Product type: HD single girder eot crane,european crane Lifting capacity: 1~30t, Span length: ≥6m, ,Working class: A5,
	European underslung single girder overhead travelling crane European underslung single girder underslung crane is installed on the roof of the workplace without bracket, saving space and lowering cost. Underslung single girder overhead travelling crane specifications: Product type: NLX single girder eot crane, Lifting capacity: 1~20t, Span length: ≥ 6m, Working class: A5,
	Suspension single girder overhead travelling crane Suspension single girder overhead travelling crane is a small light lifting equipment, economical price, which is widely used in the factory, warehouse, stockyard, etc. Suspensions single girder overhead travelling crane specifications: Product type: LX single girder eot crane, Lifting capacity: 1~10t, Span length: 3~15m, Working class: A3,

Double girder overhead travelling crane designs

When the lifts is more than 20 ton or the span is more than 31.5m, or the crane duty cycle is A7 and A8, the double girder overhead travelling crane will be the first choice.

Double girder overhead travelling crane - overhead travelling crane types of Dongqi

Two girder beams makes up the bridge, supported by an end truck or carriage on each side, with the electric trolley and hoist running on the rails, installed on the top of both bridge girders.

double girder cranes are recommended for heavier-duty applications, where lifts is more than 20 ton or the span is more than 31.5m, or the crane duty cycle is A7 and A8.
Double girder crane is selected when crane needs to be custom designed, in terms of walk ways, driver’s cabs, magnet cable reels, and others.
What more, double girder crane offers more lifting height with the top running design.

Double girder overhead travelling crane designs of Dongqi Crane

Double girder overhead travelling crane is designed to handle heavy loads and objects over 20 tons, thus, a double girder overhead travelling crane also refers to a heavy duty overhead travelling crane. Hook double girder overhead travelling crane is one of the mostly used heavy material handling equipment with the lifting capacity from 5 ton to 550 ton, working class up from A4 to A7.

Up to 550 ton double girder overhead travelling cranes of various crane designs are for sale good price. Types of double girder overhead travelling cranes are available, such as, hook overhead travelling crane, gab bucket overhead travelling crane, electromagnetic overhead travelling crane, soaking pit overhead travelling crane, etc. Contact us to get your double girder overhead travelling crane now.

	European Double Girder overhead travelling crane FEM double girder overhead travelling crane meets all the European crane standards with CE cerfiticates. Fem double girder eot crane specifications: Crane Capacity of 5~ 80 ton, Span length: 10.5~35.5m, Working class: A4~A7,
	Electric Hoist Double Girder overhead travelling crane Electric hoist double gider overhead travelling crane is widely used in machinery fabrication, metallurgical plant auxiliary workshop, storage, stock ground, and power station, textile industry and food industry. Double girder eot crane specifications: Capacity: 5~63 ton, Span Length: 8m~32m, Working Class: A3~A5,
	Hook Double Girder Overhead Orane General use hook overhead travelling crane is widely used to upload and move of normal weight in the fixed crossing space and also can work with various special-purpose hoist in special operations. Hook double girder overhead travelling crane specifications: Capacity: 5-550 ton, Span length: 10.5~35.5m, Working class: A4~A7,
	Explosion Proof Double Girder overhead travelling crane Explosion proof overhead travelling crane is designed for explosive gas atmospheres with explosion-proof electrical equipment. EX-proof double girder eot crane specifications: Capacity:5~75 ton, Span Length: 10.5~31.5m, Working Class: A4, A5,
	Electromagnetic Double Girder overhead travelling crane The electromagnetic overhead travelling crane is used in metallurgy factory or outdoor place to load and transport electromagnetic black metal materials, such as , steel ingot, merchant steel and pig iron, etc. Electromangetic double girder eot crane specifications: Capacity: 5~32 ton, Span Length: 10.5~31.5m, Working Class: A5, A6,
	Double Trolleys Double Girder overhead travelling crane The double trolley overhead travelling crane is used to lift long and big loads. Double girder eot crane specifications: Capacity: (2.5+2.5)~(200+200) ton, Span length: 10.5~35.5m
	Insulation Double Girder overhead travelling crane The insulation overhead travelling crane is used to handle electrolyse non-ferrous metals such as magnesium, aluminum. Insulation double girder eot crane specifications: Capacity: 5~50 ton, Span Length:10.5~31.5m,Working Class: A6, Ambient Temperature:-25~50℃,
	grab bucket Double Girder overhead travelling crane Grab overhead travelling crane is widely used in power station, storage, workshop, and port to load and unload scattered objects. Grab bucket double girder eot crane specifications: Capacity: 5~25 ton, Span Length: 10.5~34.5m, Working Class: A6
	Ladle Double Girder overhead travelling crane Ladle overhead travelling crane are widely used in the smelting industry to convey, pour and charge the liquid hot metal in the process of smelting. Double girder eot crane specifications: Capacity: 5~74 ton, Span Length: 10.5~31.5m, Working Class: A7, Ambient Temperature: -10~60℃,

Top running overhead travelling crane designs

top running crane is very flexible and versatile, which can be used to handle lifts with small and large capacity.

With no limiting capacity, the top running crane can be used to handle lifts with small capacities to very large capacities. Top running cranes consist a rail installed on top of each runway, with wheels move on the rail, rather than on the bottom flange of the runway beam. Supported by the building structure or runway support columns, or sister columns, top running overhead travelling crane are the first option for moving extremely heavy loads.

Overhead travelling under running crane / Underhung crane

Under running crane, also called under hung cranes, are used for lighter service and lower capacity applications, usually supported by ceiling or roof structures.

Due to the crane wheels are supported by the bottom flange of the overhead travelling crane runway beams, functioned as the crane rail, the under running crane is also called under hung cranes. This type of overhead travelling cranes can maximize the utilization of the floor space of your facility, because under running cranes are supported by the ceiling trusses or the roof structure.

With the utilization of an existing support structure (if adequate), or run on a newly-engineered support structure, the under running cranes may lower the cost of crane.

Why select Dongqi as travelling overhead travelling crane Supplier

Dongqi is a professional overhead travelling crane supplier with integrated operation of design, production, merchandising, and services. After accumulating years of experiences, both our products and service have been successfully consummated. Your will never regret after cooperating with us. Here are a part of our innovative DETAILS.
Dongqi always devoted to innovation and invented three-to-one motor to save space and improve efficiency.
Much safer device, protective nets on trolley ensure operator’s safety.
Operating on cab or hand-controlled on the ground.
Our buffer and other overhead travelling crane parts are all of high-performance and high-efficiency.

Dongqi operating rules of overhead travelling cranes

Before Operating

a. Inspection of the overhead crane components such as hook, wire rope and other safety devices, etc. before operation, ensuring the safety work.
b. Closing the power by ensuring no one standing on the walkway or track.

During Operation

a. For everyday first operating, remember to drop down the goods after lifting of 0.5 meter height to ensure safety. Starting operation after making sure of reliable property.
b. Strictly conform to ten impermissibility’s for hoisting work.
c. Stop operation after finding anomaly detection, and inspect the equipment by power cutoff.

After Operation

a. Lifting the hoisting equipment to specify height＆stop the overhead crane in fixed position, and cut off the power.
b. Keep routine maintenance.
c. Carry out perfect shift hand over working and keep detailed working log.
