20 Ton gantry crane for Sale to Vietnam
Our client from Vietnam purchased one set MGO Model
double girder gantry crane in October, 2022. And they finished installation and commissioning of this 20 ton gantry crane in this month with the help of our installation team.
We received this inquiry on 9th, October, the client was looking for a gantry crane to load and unload goods for his marble factory. our sales engineer started to contact this customer via E-mail and WhatsApp. In the initial stage, the customer just had a preliminary idea for movable gantry crane. After nearly 2 weeks of uninterrupted communication, the customer's requirements were gradually confirmed.
With the assistance of our engineers, our client was very satisfied with our design solutions. As a professional gantry crane manufacturer, we have the ability and obligation to provide our customers with high-quality pre-sales and after-sales services. After the installation was completed, this Gantry crane run in good state.
This project specifications of 20 ton gantry crane to Vietnam for your reference:
- Type: MGO Double Girder Gantry Crane
- Lifting capacity: 20 ton
- Lifting height: 9m
- Span: 10m
- Cantilever left: 3m
- Cantilever right: 3m
- Trolley traveling speed: 35m/min
- Crane traveling speed: 45m/min
- Lifting speed: 7.2m/min
- Working class: M5
- Power supply: 380v, 3phase, 50hz
- Trolley traveling power: 2.5*2KW
- Crane traveling power: 5.5*2KW
- Hoisting power: 26KW
- Total power: 42KW
- Total weight: 25600KG
- Max wheel load: 232 KN
- Protection class: IP54
- Insulation grade: F
- Ambient temperature: -20℃ ~ +40℃
- Control: Remote control
- Warranty: 12 months from date of installation or 18 months from the date of dispatch from our factory whichever is earlier.
The Vietnam client are very satisfied with this rail mounted gantry crane, it will help improve work efficiency, save time and cost for the marbles handling and moving. And this is their first phase of the project, and now the second phase of construction has started, and there will be greater procurement needs in the second phase of the project. In the following, customers will also have plan to purchase gantry crane and
jib crane. Now we have supply quotation and drawing for them.Thanks for the clients trust in our products. And we will provide high-quality products and services for our clients. Expecting for more cooperation with them again.
20 Ton Gantry Crane Supplier - DQCRANES
- 20 ton gantry crane supplied by DQCRANES is a highly efficient material handling equipment used to lift large and small loads. It is widely used for both indoor and outdoor workplaces such as port, shipyard, freight yard, construction site, stone factory and railway.
- The gantry crane 20 ton we produce mainly comes in two configurations, including single girder gantry crane and double girder gantry crane. Due to heavy lifting equipment, the single girder crane 20 ton usually adopts L type. For double girder crane, we have A type or U type gantry crane,
- DQCRANES also supply 20 ton semi gantry crane, truss gantry crane, portable gantry crane for you to choose from.
Why Choose Gantry Crane from DQCRANES?
- Compact structure, very easy to install, operate and maintain.
- Smooth starting and ending.
- Stable performance, low noise.
- High quality, less maintenance.
- Strong loading capacity, high efficiency.
- Full remote control, hand operation and cabin operation choices.
- Wonderful design, elegant appearance and advanced technology.
- High configurations, advanced motors, and electric parts.
20 Ton Gantry Crane Price
20 ton gantry crane price is important for both buyers and manufacturers. Buyers want to purchase cheap products, and gantry crane manufacturers need to keep competitiveness by favorable price. However, many suppliers usually focus on the low price of cranes but do not care about the quality.
As a reliable manufacturer, the cranes from our company has high quality and reasonable price. Before purchasing a crane, you can communicate with our sales engineer, and tell them the working condition of the crane you need. The price of a gantry crane is affected by a variety of factors.
Get 20 Ton Gantry Crane Price from DQCRANES
DQCRANES can offer factory price of 20 ton gantry crane to our clients. The gantry cranes come in various types, thus their prices differ from each other. We also supply other options for 20 ton gantry crane, such as different types of electric hoists and motors, various spreaders for different applications.
In order to get the best price, you should first determine your 20 ton crane model, specifications, such as span, lifting height, application and crane working environment. If you are not sure which type of gantry lifting equipment can best serve your needs,
contact us online. We are willing to help you find the best gantry lifting system and save cost for you. To know more about the gantry crane price, don’t hesitate to find us!
